Titan Deck
Finish Options
Architectural
- Planed Smooth
- Exposed face of member is surfaced true to specified dimensions.
- Defects over .75” diameter are patched and filled
Industrial
- Exposed face of member is surfaced true to specified dimensions.
- Filling or patching not required
- Occasional planing misses may occur
For your next mass timber project
- Ideal for low carbon construction projects
- For use as floor or roof decking
- Designed for simple span, multi span, and cantilevers applications
- Code compliant nation wide
- Sustainable, regenerative material unlike concrete and steel
- AITC Certified production facility
- Made in accordance with American National Standards Institute (ANSI A190.1)
| Property | Douglas Fir | Spruce/Pine | SYP |
|---|---|---|---|
| Bending Moment (Positive) Fb | 850 | 875 | 1250 |
| Bending Moment Fb | 850 | 875 | 1250 |
| Shear Parallel Fv | 180 | 135 | 175 |
| Compression Parallel Fc | 1400 | 1150 | 1500 |
| Compression Perpendicular Fcp | 625 | 425 | 565 |
| Tension Parallel ft | 500 | 450 | 800 |
| Modulus Elasticity E | 1,600,000 | 1,400,000 | 1,600,000 |
